Overview
In this Last Chapter we noticed when any of the buttons is pressed, the bulb switches on, now we will make a circuit, in which the bulb will only light up if both buttons are pressed! and its called and AND Gate.
Requirements
Here is a list of Components that we will need to make this Project.
| Sr# | Items | Quantity |
| 1 | Cell Holder | 1 |
| 2 | Cell 1.5 V | 2 |
| 3 | Crocodile Clips | 3 |
| 4 | Bulb | 1 |
| 5 | Bulb holder | 1 |
| 6 | Buttons | 2 |
Wiring Diagram
Here is a Complete Wiring Diagram along with Instructions for this Project
Note: Use cell + cell holder, don’t use any other battery with these bulbs
Video
You can follow this video and the instructions below to make this Amazing Project.
Did You notice anything different from the last project? share a video of your project and also try to explain in the project the difference between AND and OR gate circuits!
